Stag BM Platen Belt Grinder/Linisher
A single-ended platen belt grinder/linisher ideal for general workshop use. Bench, pedestal and dust extraction mounted models are available.
Standard features include:
- Heavy duty fabricated base and pedestal
- Direct drive
- Cast-iron work rest
- Belt tensioning and tracking controlled by duplex cams
Additional information
Electrical Supply
400/3/50 or 230V/1ph/50Hz
Motor
1.5kw
Motor Speed
1500rpm
Belt Size
150mm wide x 1090mm long
Belt Speed
6.5m/sec
Optional Extras
- Light
- Foot stop
- Heavy duty foot stop
- Lockable isolator
- Variable speed
- Re-circulation coolant system for wet grinding
